RG-S2915-24GT4MS-L

GIÁ BÁN: Liên hệ

2.5GE uplinks, overcoming GE limitations, supporting diverse access types, and enabling integration into 10GE networks
Unique CPU protection policy, ensuring stability of the switch and nonstop services
RLDP used to provide smooth network connections
10 kV surge protection for ports and high reliability
Compliance with standard protocols and application in various scenarios
Ease of use through Ruijie Cloud for management and remote O&M

ixed Service Ports

24 × 10/100/1000BASE-T ports, 4 × 1GE/2.5GE SFP ports

Management port

1 x RJ45 console port

Switching capacity

68 Gbps

Forwarding rate

51 Mpps

Capacity of MAC address table

16000

Power module

1 x fixed power module

Fan module

Cooling mode

Natural cooling

Input power

Rated input voltage range: 100V AC to 240V AC, 50/60Hz Max. input voltage range：90V AC to 264V AC, 50/60Hz

Power consumption

15.6W

Surge protection

10 kV

Dimensions (W x D x H)

440 mm × 220 mm × 43.5 mm (17.32 in. x 8.66 in. × 1.71 in.)

Temperature

Operating temperature: 0°C to 45°C (32°F to 113°F) Storage temperature: –40°C to +70°C (–40°F to +158°F)

Hardware Specifications	RG-S2915-48GT4MS-L	RG-S2915-24GT4MS-L	RG-S2915-24GT4MS-P-L	RG-S2915-10GT2MS-P-L
Interface Specifications
Fixed Service Ports	48 × 10/100/1000BASE-T ports, 4 × 1GE/2.5GE SFP ports	24 × 10/100/1000BASE-T ports, 4 × 1GE/2.5GE SFP ports	24 × 10/100/1000BASE-T ports, supporting PoE/PoE+ 4 × 1GE/2.5GE SFP ports	10 × 10/100/1000BASE-T ports, ports 1 to 8 supporting PoE/PoE+, 2 × 1GE/2.5GE SFP ports
Power modules	1 fixed power module	1 fixed power module	1 fixed power module	1 fixed power module
Fans modules	2 fixed fans	0	2 fixed fans	1 fixed fans
Fixed management ports	1 × RJ45 Console, 1 × USB port	1 × RJ45 Console, 1 × USB port	1 × RJ45 Console, 1 × USB port	1 × RJ45 Console, 1 × USB port
System Specifications
Packet forwarding rate	87 Mpps	51 Mpps	51 Mpps	22.5 Mpps
Switching capacity	116Gbps	68Gbps	68Gbps	30Gbps
MAC Table Capacity	16,000	16,000	16,000	16,000
ARP table	512
Routing Table Size (IPv4/IPv6)	64
ACL entries	500
Dimensions and Weight
Dimensions (W x D x H)	440 mm × 220 mm × 43.5 mm (17.32 in × 8.66 in × 1.71 in), 1 RU	440 mm × 220 mm × 43.5 mm (17.32 in × 8.66 in × 1.71 in), 1 RU	440 mm × 292 mm × 43.6 mm (17.32 in × 11.50 in × 1.72 in), 1 RU	297 mm × 170 mm × 44.5 mm (11.69 in × 6.69 in × 1.75 in), 1 RU
Weight	2.8 kg (6.17 lbs)	2.5 kg (5.51 lbs)	2.8 kg (6.17 lbs)	2.5 kg (5.51 lbs)
CPU and Storage
CPU	Built-in CPU, single-core processor, with the clock speed of 1.2 GHz
Flash Memory	64 MB
SDRAM	512 MB
Data packet buffer	512 KB
Power and Consumption
Maximum power consumption	< 30 W	< 15.6 W	< 33 W (non-PoE) < 403 W (PoE full load)	< 16 W (non-PoE) < 141 W (PoE full load)
Rated input voltage	100 V AC to 240 V AC, 50 Hz to 60 Hz	100 V AC to 240 V AC, 50 Hz to 60 Hz	100 V AC to 240 V AC, 50 Hz to 60 Hz	100 V AC to 240 V AC, 50 Hz to 60 Hz
Maximum input voltage	90 V AC to 264 V AC, 50 Hz to 60 Hz	90 V AC to 264 V AC, 50 Hz to 60 Hz	90 V AC to 264 V AC, 50 Hz to 60 Hz	90 V AC to 264 V AC, 50 Hz to 60 Hz
Environment and Reliability
MTBF	>200K	>200K	>200K	>200K
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-40°C to +70°C (-40°F to +158°F)
Operating Humidity	10% to 90% RH (non-condensing)
Storage Humidity	5% to 95% RH (non-condensing)
Operating noise	≤ 37 dB	Fanless	≤ 39 dB	≤ 37 dB
Interface surge protection	Power port: 6 kV/2 kV Telecom port: 10 kV	Power port: 6 kV/2 kV Telecom port: 10 kV	Power port: 6 kV/2 kV Telecom port: 10 kV	Power port: 6 kV/2 kV Telecom port: 10 kV

Software Specifications

Feature
Ethernet switching	Jumbo frame (maximum length: 9216 bytes)
	802.3az EEE
	IEEE 802.1Q (4,094 VLANs)
	Voice VLAN
	Port based VLAN
	Basic QinQ Selective QinQ
	STP (IEEE 802.1.d), RSTP (IEEE 802.1w), MSTP (IEEE 802.1s)
	ERPS (G.8032)
	LLDP/LLDP-MED
	LACP (IEEE 802.3ad)
IP service	ARP
	DHCP client, DHCP relay, and DHCP server
	DHCP snooping
	DNS
IP routing	Static routing
	RIP, RIPng
	OSPFv2
ACL and QoS
