DS-2CD2T21G1-I

Giá bán: 1.236.000 vnđ

(Chưa VAT)

1/3" Progressive Scan CMOS 2MP
Độ phân giải 1920 × 1080 @ 25fps
4/6 mm fixed lens
H.265+, H.265, H.264+, H.264
120 dB WDR, BLC, HLC, 3D DNR
Up to 50 m IR range
IP67
12 VDC ± 25%, PoE: 802.3af

Đặc tả

Cảm biến: 1/3″ Progressive CMOS
Ống kính F4mm
Độ phân giải cao 2.0 Megapixel cho hình ảnh HD 1080P HD siêu nét
Chuẩn nén hình ảnh H.265+/H.265/H.264/MJPEG
Đèn led hồng ngoại tầm nhìn xa ban đêm lên đến 50m
Tính nng thông minh chống ngược sáng thực 120 dB WDR, BLC, HLC, 3D DNR
Hỗ trợ: HIK Connect, cloud service

Camera
Image Sensor	1/2.8″ Progressive Scan CMOS
Min. Illumination	Color: 0.01 Lux @ (F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR
Shutter Speed	1/3 s to 1/100,000 s
Slow Shutter	Yes
Auto-Iris	No
Day & Night	IR Cut Filter
Digital Noise Reduction	3D DNR
WDR	DWDR
3-Axis Adjustment	Pan: 0° to 360°, tilt: 0° to 100°, rotate: 0° to 360°
Lens
Focal length	2.8/4/6 mm
Aperture	F2.0
Focus	Manual
FOV	4 mm: horizontal FOV: 86°, vertical FOV: 46°, diagonal FOV: 102°
FOV	6 mm: horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 62°
Lens Mount	M12
IR
IR Range	30 m
Wavelength	850nm
Compression Standard
Video Compression	Main stream: H.265/H.264
Video Compression	Sub-stream: H.265/H.264/MJPEG
H.264 Type	Main Profile/High Profile
H.264+	Main stream and sub-stream support
H.265 Type	Main Profile
H.265+	Main stream and sub-stream support
Video Bit Rate	32 Kbps to 16 Mbps
Smart Feature-set
Behavior Analysis	Line crossing detection, intrusion detection
Region of Interest	1 fixed region for main stream and sub-stream
Max. Resolution	1920 × 1080
Main Stream	50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
Main Stream	60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream	50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
Sub-Stream	60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement	BLC/3D DNR
Image Setting	Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser
Target Cropping	No
Day/Night Switch	Auto/Schedule
Network
Network Storage	Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger	Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
General Function	One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
API	ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View	Up to 6 channels
User/Host	Up to 32 users
User/Host	3 levels: Administrator, Operator and User
Client	iVMS-4200, Hik-Connect, iVMS-5200
Web Browser	IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
Communication Interface	1 RJ45 10M/100M self-adaptive Ethernet port
Video Output	No
On-board storage	Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
General
Operating Conditions	-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply	12 VDC ± 25%, Φ 5.5 mm coaxial power plug
Power Supply	PoE (802.3af, class 3)
Power Consumption and Current	12 VDC, 0.6A, max. 5.5W
Power Consumption and Current	PoE (802.3af, 37V to 57V), 0.2A to 0.1A, max. 8W
Protection Level	IP67
Protection Level	TVS 2000V Lightning Protection, Surge Protection and Voltage Transient Protection
Material	Metal & Plastic
Dimensions	Camera: 93.85 × 89.52 × 194.04 mm
Weight	Camera: Approx. 750g
