AC Outdoor

GIÁ BÁN: Liên hệ

The Enterprise-Grade High Perfomance WiFi 5 802.11ac Wave 2 Access Point, especially

designed for the Outdoor Envionments deployment with High-Throughput-Demand

Highlights

Ideal Use Cases

Performance-critical wireless LANs

High-density outdoor environments

Operation Management

Support fixible mode FIT(Wlan Controller Member) and FAT(Stand Alone AP)

Central-provisioning from Wlan Controller.

Self configuration one by one AP via WEB GUI.

Suport flexible network mode operation: AP, AP Router, WDS Wireless Link, ISP Client.

Hardware Features

2 radios: 2.4 GHz, 5 GHz, dual-band

802.11N, 802.11AC Wave2 1200Mbps.

2 × 1 Gbps Ethernet port (WAN, LAN)

PoE: 802.3at

Suport 12Volt DC input.

Wire Network Optimization

Support Multi 4SSID/Vlan tag per radio.

MAC ACL in the FAT mode.

Router support DHCP Server and Bandwidth QOS in FAT Mode.

Router support port forwarding and DMZ.

Monitor and track statement of the online client devices.

Wlan Network Optimization

Auto channel selection by AP self in the Passive mode in FAT mode AP.

Auto channel provision from the cental Wlan Controller with flexible mode Passive and Active when working in FIT mode AP.

Radios optimized for rate-vs-range performance

Built-in real-time RF spectrum view in FAT mode.

Wlan Controller-based automatic roaming assistant(Client’s match decision).

Support Band Streering Prefer 5Ghz.

Support Fast Roaming 802.11k,v,r

Device management

Create device-specific firewall rules

Schedule reboot system.

Schedule on/off Wlan Radio WiFi.

Central Firmware Management or Direct Firmware Upgrading

Local syslog.

Specifications
Model	AP1200
802.11 Standard	802.11 A/N/AC 5.8Ghz
Data Rate	1200Mbps
Antenna	MIMO Panel Integrated 2×2:2 Antenna With 5 dBi
Transmit Power	High
Beamwidth	360°
Chanel Bandwidth	20/40/80 Mhz
Network Interface	(2) x 10/1000 Mbps Ethernet Ports
Power Method	802.3af/at PoE 48V Passive PoE (Pairs 4,5+ & 7,8-) 12V 1.5A DC Jack
Features	Wireless AP, Router AP, WDS Link, Client ISP Wan Interface: DHCP Client, Static, PPPoE Multiple 4 SSID/radio Vlan/SSID 802.1q Wlan Security: Open, WPA/WPA2-PSK RF Optimization configuration Firewall: DMZ, Port forwarding, ACL L3/L4, MAC Binding. System Firmware, backup restore configuration System time zone FIT MODE: Wlan Controller
Max Power Consumption	<13W
IP Ratings	IP65
Assistant Interface	(1) Reset button, press 15 seconds for default setting
LEDs	1 Power, 1 WAN, 1 LAN and 4 Wi-Fi Signal Strength LEDs
ESD/EMP Protection	Contact Discharge: ±6KV Air Discharge: ±8KV
RF Power	2.4G RF Power 802.11b 11M 21±2dBm 1M 23±2dBm 802.11g 54M 20±2dBm 6M 22±2dBm 802.11n HT20 MCS7 19±2dBm MCS0 21±2dBm 802.11n HT40 MCS7 18±2dBm MCS0 20±2dBm 5G RF Power 802.11a 54M 19±2dBm 6M 21±2dBm 802.11n HT20 MCS7 18±2dBm MCS0 20±2dBm 802.11n HT40 MCS7 17±2dBm MCS0 19±2dBm 802.11ac HT80 MCS9 16±2dBm MCS0 18±2dBm
Receive Sensitivity	2.4G Receive Sensitivity 802.11b 11M -85dBm 1M -94dBm 802.11g 54M -72dBm 6M -90dBm 802.11n HT20 MCS7 -70dBm MCS0 -88dBm 802.11n HT40 MCS7 -68dBm MCS0 -86dBm 5G Receive Sensitivity 802.11a 54M -74dBm 6M -90dBm 802.11n HT20 MCS7 -72dBm MCS0 -88dBm 802.11n HT40 MCS7 -68dBm MCS0 -86dBm 802.11ac HT80 MCS9 -58dBm MCS0 -80dBm
Dimensions	315mm * 145 mm * 80 mm
Environment	Operating Temperature: -30~55 ℃ Max Operating Temperature: -40~70 ℃ (Throughput lower) Storage Temperature: -40~70 ℃ Humidity: 5%~95% non-condensing
Management	Firmware GUI ,Remote Management, Wlan Controller
